Are you looking to reference Lavabo dimensions for the most sensible placement of water supply and drainage pipes? Currently, there are numerous lavabo sink manufacturers, each with slightly different sizes. However, the variations in size are negligible. So, feel free to explore the standard and common lavabo sizes shared below.
The standard height of a lavabo, measured from the ground up, is 800mm. For individuals taller than 1.75m, the lavabo height ranges from 850-900mm. Here are the dimensions of some commonly used lavabo sinks from Inax and Toto.
Dimensions of Wall-Mounted Lavabo Sinks
Wall-mounted lavabo sinks are the most common type, including corner lavabo sinks for small bathroom spaces.
Standard dimensions of wall-mounted lavabo sinks are as follows:
- Height of wall-mounted lavabo sink: approximately 150-220mm.
- Width of wall-mounted lavabo sink: approximately 350-430mm.
- Length of wall-mounted lavabo sink: approximately 400-500mm.
- Height for concealed drainage pipe fitting, measured from finished floor to the center of the toothed hole: 510mm.
- Height for concealed cold and hot water supply pipe fitting, measured from finished floor to the center of the outer rabbet d=21: 620mm.
You can find detailed size specifications of some wall-mounted lavabo sinks from Inax and Toto below.
Some Wall-Mounted Lavabo Sizes by Inax, Toto
- TOTO LT236CS Washbasin
Dimensions: 530x465x210mm (length x width x height)
- TOTO LT240CS Washbasin
Dimensions: 500x350x180 mm
- TOTO LT210CTR Washbasin
Dimensions: 500x400x220 mm
- TOTO LT300C/LT300CM Washbasin
Dimensions: 430x500x190 mm
- Inax L-283V Wall-Mounted Lavabo Sink
Dimensions: 429x390x162mm
- Inax L - 280V Wall-Mounted Lavabo Sink
Dimensions: 400x322x150mm
- INAX L-282V Wall-Mounted Lavabo Sink
Dimensions: 400 x 410 x 180mm
- INAX L-284V Wall-Mounted Lavabo Sink
Dimensions: 425 x 495 x 145 mm
Standard Sizes of Countertop Lavabo Sink
Standard dimensions of countertop lavabo sink are as follows:
- Height of countertop lavabo sink: approximately 175-210mm.
- Width of countertop lavabo sink: approximately 380-450mm.
- Length of countertop lavabo sink: approximately 550-600mm.
- Height for concealed drainage pipe fitting, measured from finished floor to the center of the toothed hole: 500mm.
- Height for concealed cold and hot water supply pipe fitting, measured from finished floor to the center of the outer rabbet d=21: 620mm.
You can explore more detailed size specifications of some Inax, Toto countertop lavabo sinks below.
Some Sizes of Countertop Lavabo Sinks by Inax, Toto
- INAX AL-2298V Countertop Lavabo Sink
Dimensions (mm): 550 x 400 x 210
- INAX L-2216V Countertop Lavabo Sink
Dimensions: 550 x 380 x 175 mm
- INAX AL-2094V Countertop Lavabo Sink
Dimensions (mm): 589 x 515 x 190 (Length x Width x Height)
- INAX GL-2293V (AL-2293V) Countertop Lavabo Sink
Dimensions: 415 x 535 x 210 mm
- TOTO LT546 Inset Lavabo Sink
Dimensions: 550x400 mm
- TOTO LT764 Inset Lavabo Sink
Dimensions: 540x460 mm
- TOTO LT548 Inset Lavabo Sink
Dimensions: 600x420 mm
- TOTO LT520T Inset Lavabo Sink
Dimensions: 604x365 mm
Standard Sizes of Countertop Lavabo Sink
Standard dimensions of countertop lavabo sink are as follows:
- Height of countertop lavabo sink: approximately 70-180mm.
- Width of countertop lavabo sink: approximately 380-450mm.
- Length of countertop lavabo sink: approximately 400-600mm.
- Height for concealed drainage pipe fitting, measured from finished floor to the center of the square hole for the 34mm fitting: 510mm.
- Height for concealed cold and hot water supply pipe fitting, measured from finished floor to the center of the outer rabbet d=21: 620mm.
You can explore more detailed size specifications of some Inax, Toto countertop lavabo sinks below.
Some Sizes of Countertop Lavabo Sinks by Inax, Toto
- INAX AL-296V Countertop Lavabo Sink
Dimensions: 570x450x180 mm.
- INAX L-296V Countertop Lavabo Sink
Dimensions: 570 x 450 x 180 mm.
- INAX GL-445V (AL-445V) Countertop Lavabo Sink
Dimensions: 450 x 450 x 165 mm (Length x Width x Height).
- INAX L-333V Countertop Lavabo Sink
Dimensions: 449 x 440 x 115 mm (Length x Width x Height).
- TOTO LT4706 Countertop Lavabo Sink
Dimensions: 600x420x90mm.
- TOTO LT4716 Countertop Lavabo Sink
Dimensions: 600×380×70mm.
- TOTO LT4724 Countertop Lavabo Sink
Dimensions: 400x260x80mm.
- TOTO LT5716 Countertop Lavabo Sink
Dimensions: 600x380x70mm.
Above are the dimensions of some standard and commonly used lavabo sinks by Inax, Toto. Hope you can choose a suitable lavabo and design the water supply and drainage system most reasonably. Wish you success!
