How do exoplanets, or planets outside our solar system, appear? This illustration presents a range of possibilities. The first exoplanets were identified in the 1990s. NASA/JPL-CaltechImagine the planets we're all familiar with: Mercury, Venus, Earth, and so on. They're safely orbiting our sun, part of the solar system's circle. But we're not alone. Like we have distant relatives in other cities or countries, our planets have distant relatives too — these are known as exoplanets.
An exoplanet, or extrasolar planet, is a planet similar to Earth but orbiting another star. The term "extrasolar" refers to planets beyond our solar system. For much of history, astronomers could only study planets within our solar system, though they speculated about the existence of others based on our sun's calculations. The first of these faraway worlds was discovered in the 1990s, and since then, our cosmic family tree has grown significantly.
Discovering Exoplanets
So how do we find these distant cosmic relatives? By using advanced telescopes and specific methods. One common technique is called the transit method. Imagine a child running across a lit window at night — when this happens, the light briefly dims. In a similar way, when an exoplanet passes in front of its star, it causes a small, brief drop in the star’s brightness.
Another method employed is radial velocity, which detects slight "wobbles" in a star's position due to the gravitational influence of an orbiting planet.
Lastly, we have the technique of microlensing. This is used to identify planets that don't orbit a star or are located far away from Earth. A massive object, like a star, can distort and amplify the light from a star behind it, a phenomenon known as gravitational lensing. When a planet orbits the foreground star, it alters the magnified light in a way that can be detected, signaling the presence of the planet.
Telescopes like the retired Kepler space telescope and the active TESS (Transiting Exoplanet Survey Satellite) have played a crucial role in locating exoplanets beyond our solar system. A planet discovered by Kepler is known as a Kepler planet. During Kepler's nine-year mission (2009-2018), over 2,600 planets were found. Thanks to Kepler and other telescopes, over 5,000 exoplanets have been identified as of 2023. This includes planets like GJ-1214b and Gliese-581c.
What Are the Primary Types of Exoplanets?
The over 5,000 exoplanets confirmed in our galaxy so far fall into four main categories, as listed above. NASA/JPL-CaltechAlthough exoplanets share certain characteristics with the planets in our solar system, they come in a fascinating variety of types. Here are the primary ones:
- Gas Giants: Massive planets equal to or larger than Jupiter. Some, known as "Hot Jupiters", orbit close to their stars and are extremely hot.
- Super-Earths: Rocky planets larger than Earth but smaller than Neptune. They may or may not have atmospheres. The term "Super-Earth" refers to their size, not their similarity to Earth.
- Neptunian Planets: Planets roughly the size of Neptune, with atmospheres primarily composed of hydrogen or helium. These planets are common outside our solar system but do not exist within it (as far as we know).
- Terrestrial Planets: Earth-sized planets, mostly composed of rock and metal, with water or atmospheres that might support life.
Some of the most intriguing exoplanet observation has centered around finding planets that could be habitable. In order for planets to be considered possibly habitable, they have to reside in habitable zones. These are areas in space where the planet is not too far nor not too close to its star, meaning its surface temperature is not too hot nor too cold. That gives the possibility of liquid water. Habitable planets would also need to be rocky planets, so that trees and animals would have a surface to live on. A 2020 study suggests there could be as many as 300 million potentially habitable planets in our galaxy alone. We don't know how many of them have atmospheres or oceans.
Another interesting planet type is rogue planets. These are planets that orbit no stars. These were once thought to be rare but a 2021 study put the number at between 70 and 170 in the Milky Way alone. Some of these might be gas giants while others might Earth-sized.
The Future of Exoplanet Exploration
Exoplanets are like pieces of a cosmic puzzle. By studying them, we get to understand what they're made of and what conditions prevail on these distant worlds. We use powerful tools like the Hubble Space Telescope and the newly launched James Webb Space Telescope (JWST) to analyze light passing through an exoplanet's atmosphere — a process known as spectroscopy. This gives us precious clues about the planet's atmospheric composition and temperature. JWST is specialized to observe infrared wavelengths and can penetrate the hazy atmospheres of many planets to see what lies beneath.
There are also future missions like the European Space Agency's spacecraft PLATO (PLAnetary Transits and Oscillations of stars) telescope and ARIEL (Atmospheric Remote-sensing Infrared Exoplanet Large-survey). PLATO, expected to launch in 2024, is structured to learn how planets form and which conditions might be favorable for life. ARIEL, expected to launch in 2029, will specifically target and study exoplanets.
These distant exoplanets provide answers to some of the grandest questions about our universe. How do planetary systems come into being? Which stars host planets? Is our solar system unique, or are we just one of many in the galaxy? The coming decades of exoplanet exploration are sure to bring an exciting wave of new discoveries.
Key Exoplanets Discovered
HD 189733b’s striking cobalt blue appearance is not due to reflections of ocean waters, but rather from its hazy, scorched atmosphere filled with silicate clouds. Its winds are so fast they reach up to seven times the speed of sound. On this planet, getting caught in a rainstorm could mean being pelted by glass shards blown sideways in a violent, glass-filled rain. ESO/M. KornmesserWhile all exoplanets are captivating, some stand out due to their extraordinary features, possible habitability, or the remarkable stories behind their discovery. Here are just a few of these intriguing worlds.
51 Pegasi b
This was the first exoplanet discovered orbiting a star similar to our sun. 51 Pegasi b, also known as Dimidium, was found in 1995, marking a turning point in the quest to find exoplanets. As a Hot Jupiter, this gas giant orbits incredibly close to its star (completing an orbit every four Earth days), resulting in scorching surface temperatures. Located about 50 light-years from Earth, this exoplanet opened a new chapter in space exploration.
Kepler-22b
Unveiled by NASA's Kepler Space Telescope in 2011, Kepler-22b was the first planet discovered within the habitable zone of its star — the region where liquid water might exist. While we can’t confirm if it’s a water world, it remains an intriguing possibility. This super-Earth lies over 600 light-years away and has a moderate surface temperature of 72°F (22°C). Its orbital period is 290 Earth days.
Proxima Centauri b
Say hello to our closest exoplanet neighbor: Proxima Centauri b. Situated just over four light-years away, this Earth-sized planet orbits within the habitable zone of its red dwarf star, Proxima Centauri, the star nearest to our sun. Its orbit takes about 11 Earth days.
Kepler-186f
Kepler-186f was the first Earth-sized planet discovered orbiting within its star's habitable zone. Its discovery in 2014 confirmed the existence of Earth-sized planets in the habitable zones of stars beyond our solar system (earlier findings had only revealed much larger planets). Kepler-186f orbits its red dwarf star in 130 days and receives only one-third of the energy from its star compared to Earth’s energy from the sun, placing it at the outer limit of its habitable zone.
Kepler-452b
Discovered in 2015, Kepler-452b became the first near-Earth-sized planet found within the habitable zone of a star like our sun. Its orbital period of 385 Earth days closely mirrors Earth's, making it one of the most Earth-like planets discovered in terms of size, temperature, and the type of star it orbits.
HD-189733b
HD 189733b may seem like a stunning blue world from a distance, but don't let its appearance fool you. This gas giant experiences molten glass rains and winds that whip across its surface at a staggering 5,600 miles (9,000 kilometers) per hour. The winds are so intense that they push the glass sideways instead of letting it fall. With an orbit that only takes two days, the temperature here reaches an extreme 1,700 degrees Fahrenheit (930 degrees Celsius).
WASP-12b
Next, let's venture to the incredibly dark world of WASP-12b. This Hot Jupiter is so dark it absorbs almost all the light that touches it, making it one of the least reflective exoplanets known. Discovered in 2008, it reshaped our understanding of planetary appearance. Orbiting its star in just a single Earth day, the planet reaches scorching temperatures of 4,000 degrees Fahrenheit (2,210 degrees Celsius), slowly unraveling as its star edges closer to consuming it in about 10 million years.
Exoplanets typically get their names based on the stars they orbit, with small letter labels indicating the order of discovery. But if the system is meant to be straightforward, why are the names so complex? The reason lies in the inclusion of coordinates, akin to the galactic version of latitude and longitude, giving their names an often intricate and convoluted structure.
