Robert Frost:
At present, astronauts and cosmonauts make their return to Earth aboard a Soyuz capsule. The Soyuz features a curved ablative heat shield designed to prevent the intense heat from entering the crew cabin.
As the capsule speeds through the atmosphere, it collides with air molecules, which then ricochet off the capsule and hit those behind it. This creates a shockwave in front of the vehicle. The highest temperatures occur within the shockwave, so positioning it farther from the capsule helps minimize the heat experienced by the vehicle. The capsule's curvature plays a key role in this displacement.
Some heat still reaches the vehicle’s surface, and that's where the ablative heat shield comes into action. As the outer molecules of the shield absorb heat, they eventually vaporize and escape from the surface. In the process, they carry away the heat they absorbed. This process is called pyrolysis. The next layer then heats up until it vaporizes and removes its own heat. Over time, the vehicle slows down, and the remaining heat on the surface becomes negligible, leaving the exterior relatively cool.
The goal is to design a heat shield with the correct curvature, ablative properties, and thickness, ensuring that most of the heat never reaches the crew compartment or essential equipment.
