The CMOS battery ensures that the CMOS chip retains its settings even when the computer is powered off. Catherine Falls Commercial / Getty ImagesEvery personal computer includes a small battery on the motherboard that powers the CMOS (Complementary Metal Oxide Semiconductor) chip. This battery maintains system settings like the hard disk configuration, date, and time, even when the device is turned off. A typical CMOS battery can last for about five years, and the more frequently the computer is used, the longer the battery will stay functional.
How Can You Tell If Your CMOS Battery Is Failing?
Here are some clear signs that your battery might be failing:
- The keyboard behaves erratically, with unresponsive keys and cursor.
- An invalid configuration message pops up on your screen.
- ‘Run Setup’ message appears on the screen.
- ‘Press F1 to continue’ shows up on your screen.
- After pressing F1, an ‘Invalid drive specification’ message appears.
- You see a Clock Error or similar clock-related message on your screen.
- The computer's clock loses track of time.
- The wrong date keeps showing up on the computer.
If you notice any of these signs, it's probably time to replace your computer's battery. Without a replacement, the battery will eventually fail, and you may be left with a blank screen and lost CMOS memory.
How to Recognize the Need for CMOS Battery Replacement
When your computer, either desktop or laptop, shows signs of CMOS battery failure, it's a clear indicator that the battery, usually a lithium one, is nearing its end. A failing CMOS battery can cause problems with booting your system because the BIOS settings, which allow the operating system to interface with the hardware, get reset or lost.
How to Replace a CMOS Battery
Changing the CMOS battery is a simple task, but it requires some attention to detail to prevent any harm to your computer's internal components. Here's a basic guide for removing and replacing the battery:
- Prioritize Safety: Before you begin, power off your computer and disconnect all cables and devices to avoid any risk of electrical damage.
- Locate the Battery: On desktop systems, open the case to reach the motherboard. For laptops, the CMOS battery might be found underneath a panel on the bottom or possibly beneath the keyboard.
- Remove the Old Battery: The CMOS battery is generally secured by a small clip. Gently move the clip aside to free the battery. Be careful not to apply too much pressure that could damage the motherboard.
- Insert the Replacement: Ensure the new lithium battery matches the old one in type. Place it in the battery socket, ensuring the positive side is facing upwards.
- Reassemble and Check: After inserting the new battery, reassemble the computer and reattach the casing. Connect all cables, power up the computer, and check that the BIOS settings are correct. Also, verify that the date and time are accurate.
Post-CMOS Battery Replacement
Once you've replaced a faulty CMOS battery, you might need to enter the BIOS again. This could be necessary because the BIOS settings may reset to their default configuration, which might not be optimal for your system. Make sure you know how to enter the BIOS setup (usually by pressing F2, Delete, or Esc during startup) to make any necessary adjustments.
