Funicular railways combine the mechanics of elevators with traditional railroad systems. Alex Saurel / Getty ImagesThe funicular railway integrates elevator mechanics (cables pulling a car upwards) with railroad technology (a car moving on tracks). Originally developed in the 15th century to transport people and goods up steep slopes, modern funiculars are commonly used to transport skiers to mountain peaks. In the U.S., they are frequently referred to as incline railways or double inclined elevators.
Traditional trains cannot ascend steep slopes due to insufficient traction between steel wheels and rails. Mountain-climbing trains typically use spiraling tracks or multiple switchbacks to navigate such terrain.
You may wonder why trains aren’t built with rubber tires to gain better traction on steep slopes. The primary reason trains use steel wheels and tracks is to reduce rolling resistance, which is crucial for efficiency.
Rolling resistance is a force that slows down wheeled vehicles, caused by the vehicle's weight compressing the tires. Even with rubber tires, achieving sufficient traction on steep inclines would remain a significant challenge.
Funicular Railways
The cable railway elegantly solves these challenges. By using a cable to pull the car uphill, traction issues are eliminated. The wheels simply guide the car along the track without providing any pulling force.
The brilliance of the double inclined elevator lies in its use of two cars simultaneously, one on each side of the top pulley. This design ensures that the weight of one car counterbalances the other, creating an efficient and balanced system.
The weight of the descending car assists in pulling the ascending car uphill, while the ascending car ensures the descending car's speed remains controlled and stable.
A motor drives the pulley, but its primary role is to counteract the weight difference between the two cars (due to passengers) and to manage the system's friction.
The Kitzstenhorn Cable Car
At Austria's Kitzsteinhorn glacier, where the accident occurred on November 11, 2000, two cars transport numerous visitors up and down the mountain using a single cable looped around pulleys at the summit and base.
The Kitzsteinhorn cable car operates on electricity generated by a power station at the mountain's peak. An electric motor at the top drives the cable, while a passive pulley at the base maintains tension in the cable loop.
The Austrian funicular features a single track running up the mountain, with a brief section in the middle splitting into a double track to allow the two cars to pass each other.
The Montmartre Funicular
Located in Paris, the Montmartre funicular is not only a practical transport solution for navigating the steep hill but also a historical landmark. It offers a picturesque journey through one of the city's most famous districts.
Since its opening in 1990, this beloved tourist spot has undergone several upgrades and redesigns. The electric cable railway functions as a public transport option, accommodating over 2 million passengers annually.
Building a Double Inclined Elevator
A double inclined elevator, often referred to as a funicular railway, operates on the principle of two counterbalanced cars moving in opposite directions on a shared track. This design ensures energy efficiency and balance, with one car ascending as the other descends. Below is a deeper dive into its mechanics:
Physical Setting
Constructing a funicular railway is a complex endeavor, often undertaken on steep landscapes like mountains or hills. For instance, the Kitzsteinhorn, standing at 10,499 feet (3,200 meters), features a tunnel for its funicular that exceeds the mountain's height, stretching 11,483 feet (3,500 meters).
This introduces several engineering hurdles:
- Stability and foundation: Building on steep slopes requires thorough geological assessments to ensure ground stability. The foundation must support the weight of tracks, cars, and passengers while enduring environmental stresses like wind, rain, and snow.
- Track laying: Tracks must be precisely aligned to maintain parallelism and a consistent gradient. Any misalignment can lead to dangerous imbalances, especially at high speeds.
- Tunneling: For railways passing through mountains, such as Kitzsteinhorn, tunneling is critical. Achieving such lengths demands advanced machinery and meticulous planning to ensure safety and operational efficiency.
Underground Funiculars
While many funiculars are celebrated for their breathtaking mountain views, they also play a crucial role underground. These subterranean incline railways have been developed for various purposes:
- Mining: Funiculars were among the earliest solutions for mining operations. They offered a more efficient way to transport workers and materials in deep mines, outperforming traditional hoisting systems in both speed and energy efficiency.
- Cave exploration: Some of the planet's most expansive caves feature funicular systems. These railways enable researchers and visitors to navigate safely and swiftly into the earth's depths.
- Urban transportation: In cities with steep or uneven landscapes, funiculars act as a practical public transport option. They bridge higher and lower areas, easing traffic congestion and providing a distinctive travel experience.
Funicular railways stand as remarkable achievements in engineering. Whether ascending towering peaks, exploring underground depths, or enhancing urban mobility, they showcase human creativity and technical prowess.
