Knowing how to properly install an extractor fan also allows you to comfortably install the product in any desired location. If your kitchen undergoes any changes, you can proactively relocate the extractor fan. Therefore, to ensure proper installation, you can refer to the extractor fan installation guide in the following sections.
2. Most Effective Exhaust Fan Installation Guide
2.1. Prepare Sufficient Tools and Disassemble Parts Before Installation
You need to prepare the necessary tools before installing the extractor fan, such as screwdrivers, drills, measuring tape... Then, you need to disassemble the parts and thoroughly check them before installation.
2.2. Identify the Correct Type of Extractor Fan to Install
Depending on the kitchen layout and your usage needs, you can choose a suitable, cost-effective extractor fan. Some current extractor fan products include classic extractor fans, under-cabinet extractor fans, ducted extractor fans...
2.3. Position Determination and Suitable Distance
It's crucial to consider the position when installing a kitchen hood. Not only other kitchen appliances like cabinets or stoves, but also the selection of the exhaust pipe for the hood is closely related and depends on where you install the hood. Experts recommend installing the hood before installing the stove, which will make it easier.
The key point is the minimum distance from the bottom of the hood to the stove should be about 50cm for electric stoves and 65cm for gas stoves.
2.4. Precise Measurement for Proper Installation
Measuring the dimensions of the installation site should match or exceed the hood's size for easier installation. If you don't measure accurately, you may end up with an ill-fitting hood, leading to having to purchase another product or completely changing the kitchen cabinets. This is extremely important in today's hood installation instructions.
2.5 Choosing the Right Smoke Pipe for Hoods Using Pipes
Different models of hoods require different installation methods, so the exhaust duct also depends heavily on the type of hood chosen.
- Classic hood models usually use exhaust ducts from Ф 90 to Ф110.
- Curved glass or straight glass hood models use exhaust ducts from Ф110 to Ф150.
When preparing the wall vent for the exhaust duct, if you make the vent too large, it will affect aesthetics, but if it's too small, it will increase the noise of the hood. Currently, experts recommend having a wall vent size of Ф110, which is suitable for most hood models on the market.
2.6. Pay Attention to Reading the Installation Manual Carefully
The final and equally important note is that you should read the installation manual carefully that comes with these hood products to understand the correct installation and disassembly steps.
3. Detailed Installation Steps
3.1. Steps for Installing Wall-Mounted Classic Smoke Extractor
To be able to install a wall-mounted classic smoke extractor by yourself, refer to the following guide:
- First, measure the distance from the stove to the bottom of the smoke extractor. Typically, manufacturers recommend a distance from the stove to the bottom of at least 70cm.
- Then, measure the distance between the two hanging holes of the extractor on the wall. Mark the center and drill at the marked position using a drill bit sized from 8 to 10mm.
- Install expansion plugs and screws appropriate to the drill bit size, ensuring the screws are inserted into the wall at least 4.5cm deep. Finally, hang the extractor on the newly installed screw positions.
3.2. Steps for Installing Glass Smoke Extractor
As for glass smoke extractor products, follow these installation instructions:
- Measure the distance from the stove to the bottom of the extractor, which should be between 65 and 75 cm.
- Once you've determined the installation position, proceed to attach the hanging hooks and place the inner bracket inside the extractor onto these hooks.
- Next, attach the outer bracket to the extractor, then attach the extended bracket.
- Place the glass face directly onto the extractor, then use screws to attach this glass face, pass the extractor's exhaust pipe through the wall, then adjust the bracket and the extractor to fit properly and secure them with screws.
- Finally, adjust the bracket and the extractor body, securing them with screws.
3.3. Steps for Installing Built-in Hood
For built-in hood products, follow these installation instructions:
- On the top of this hood, there are 4 screw mounting positions. Measure the position of the air vent and its diameter, mark it, and drill the vent hole on the cabinet.
- Determine the location where you will attach the hood to the kitchen cabinet. Lift the hood and screw it into the 4 positions.
- Then proceed to install the exhaust pipe, power source, and test the machine.
Proper installation of the hood, widely used by many families nowadays, will help make the most of the product's features, save costs, ensure normal operation, and even better health for your family. Additionally, the various types and beautifully designed hoods can enhance the elegance and modernity of your kitchen space. As a modern kitchen appliance, housewives need to pay attention to effective hood cleaning methods, keeping it as clean as new, or useful reviews for those intending to purchase this product with 7 beautifully designed, high-capacity hoods. Surely, with these free, useful guidebooks, you will become a perfect housewife in everyone's eyes!
